JS500 concrete mixer

JS500-1500 Concrete Mixer developed by our company is widely used by our global users. This machine can be used as a separated mixing machine or used as the supporting machine of the ready mix concrete plant. When matched with batching plant, they can form a simple mixing plant.


Features and Benefits:

Features of JS500 Concrete Mixers:

1. As a miniature double-horizontal-shaft forced type concrete mixer, this concrete mixing machine features short mixing time, good homogeneity and reliable operation.

2. Shaft tip is sealed by floating-ring, which is reliable and easy to maintain and replace.

Application of JS500 Concrete Mixers:

This concrete mixer can be used to mix stiff-consistency concrete, semi-stiff-consistency concrete, light weight aggregate concrete and so on.Features of JS500 Concrete Mixers:
1. As a miniature double-horizontal-shaft forced type concrete mixer, this concrete mixing machine features short mixing time, good homogeneity and reliable operation.

2. Shaft tip is sealed by floating-ring, which is reliable and easy to maintain and replace.




Technical Specification of JS500 Concrete Mixers:

Model: JS500
Discharge volume: 500L
Charging volume: 800L
Theoretical capacity: ≥25m3
Aggregate sizes: ≤60/80mm
Working circle: 60s

Mixing blade
Speed: 35r/min
Quantity: 2×7
Mixing motor
Model: Y180M-4
Power: 18.5 kw
Lifting motor
Model: YEZ132S-4
Power: 5.5 kw

Pump motor
Model: 50DWB20-8A
Power: 0.75 kw
Weight: 1500kg
Dimensions (L x W x H): 3030x2300x2680 mm
